| Parameter | Value |
| Pixel Pitch | 0.90909mm |
| Packaging method | COB flip chip |
| Module Physical Resolution (W*H) | 176Γ88=15488pixels |
| Module(Virtual pixel) resolution(WΓH) | 352Γ176=61952pixels |
| Physical Pixel Density (pixel/sq.m.) | 302,500dot/m2 |
| Virtual pixel density | 1,210,000 dot/m2 |
| Module Size (W*H*D) | 320mmΓ160mmΓ12.57mm |
| Single-module power consumption | 11W |
| Module Weight | 0.5kg |
| Interface Definition | HUB320 |
| Single-dot-Brightness Calibration | Support |
| Brightness | 600 cd/m2 |
| Color Temperature | 6500K~25000K adjustable |
| Beam Angle (Hor/Ver) | 160Β°/160Β° |
| Brightness/Color Uniformity | β₯95% |
| Contrast Ratio | 10000:1 |
| Input Power <Max> | 283 W/γ‘ |
| Average power | 95 W/γ‘ |
| Power Supply Requirement | AC 100 V ~ 240 V(50&60Hz) |
| Module power supply voltage | 4.5V |
| security feature | GB4943/EN62368 |
| Frame Changing Frequency | β₯60 frames per second |
| Drive mode | Constant Current Driving |
| Scanning method | 44S |
| Refresh Rate | β₯4200Hz |
| Processing Depth | 14Bit |
| Working Temp/Humidity(C/RH) | 10Β°Cβ45Β°C / 10%-80%RH(No condensation) |
| Storage Temp/Humidity(C/RH) | 40Β°Cβ60Β°C / 10%-90%RH(No condensation) |
